Installation, Use and Maintenance Of Prepaid Water Meter

1. The water meter diameter should be selected according to the diameter of the public pipeline and the flow rate required by the user.
2. The water meter must be installed on a straight section of the pipeline. The length of the straight section between the valve before the meter and the water meter is important. It is recommended that the valve be opened to its maximum during use.
3. The water meter should be installed in a location that avoids exposure to sunlight, flooding,
4. freezing, and pollution, and is easy to install, disassemble, and read. Rain and freeze protection measures should be taken during the rainy season and winter.
5. Before installation, the pipes should be cleaned to remove construction mud, sand and other debris to prevent water meter malfunction.
6. A valve should be installed in front of the water meter to cut off the main water supply when the water meter is being maintained.
7. The water meter should be installed horizontally, with the dial facing upwards, and the arrow on the meter casing must point in the same direction as the water flow.
8. If the water meter is installed at the boiler inlet pipe, hot water backflow should be prevented to scald the water meter.
9. The water meter should be installed as far away as possible from sources of strong magnetic or
10. electrical interference. If the water meter is installed inside a meter well, it should be installed as close to the well opening as possible. The meter box and cover should be made of non
11. metallic materials to avoid affecting the water meter’s communication performance.
12. If the water meter reports a discrepancy between the meter reading and the mechanical reading, or if the water meter fails to report any data, the mechanical reading of the water meter shall prevail.

Transportation and Storage Of Prepaid Water Meter

1. This product should be protected from collisions or severe impacts during transportation.
2. Water meters should be stored in an indoor place with a dry and well-ventilated environment, where the air does not contain corrosive media. The ambient temperature should be between 5℃ and
3. 50℃, and the relative humidity should not exceed 90% . The storage time of water meters should not exceed 6 months.

After-sales service

For products that are properly installed, have normal flow rates, and whose quality issues are not caused by human error, and whose seals are intact, our company provides a one-year free warranty.
