The centralized monitoring system of power environment in intelligent distribution room is an advanced system integrating computer network, database technology, communication technology, automatic control technology and sensor technology.
The system realizes comprehensive monitoring, safety protection and video surveillance of the distribution room environment through the coordinated work of multiple subsystems such as temperature and humidity monitoring subsystem, water leakage monitoring subsystem, smoke detection subsystem, video monitoring subsystem, and access control subsystem.
01. System advantages
1. High security and reliability: The system uses an embedded monitoring host and runs the Linux operating system, which effectively avoids the instability and security issues of the Windows system and improves the overall stability and reliability of the system.
2. Simple wiring and easy maintenance: The monitoring host adopts a hardware and software integrated design, which is highly integrated, has low power consumption and long service life. At the same time, various monitored devices and sensors are installed using RJ45 interfaces, powered by the host, plug-and-play, easy to construct, and simple wiring.
3. Complete IE management and browsing: The system adopts B/S architecture. Ordinary office computers/notebooks can conveniently manage the system anytime and anywhere through a Web browser. There is no need to install additional client software, making it more convenient to use and maintain.
02. Collect data
1. Power monitoring: The system can monitor the operating parameters and working status of power equipment such as AC input, distribution switches, DC/AC distribution panels, static switch cabinets (STS), dynamic switch cabinets (ATS), UPS, battery packs, generators, transformers and cable temperature measurement in real time.
2. Environmental monitoring: The system can monitor environmental parameters such as temperature and humidity, water leakage, water level, water pump control, lighting, lightning protection status, gas concentration and noise in important areas of the distribution room to ensure the safety and comfort of the distribution room environment.
3. Security monitoring: The system realizes the security protection and personnel management of the distribution room through access control management, video image monitoring, fire monitoring, anti-theft monitoring and electronic fence monitoring.
03. System functions
1. System interface: Provide an intuitive and friendly user interface to facilitate users to manage and operate the system.
2. Automatic start upon incoming call: The system has the function of automatic start upon incoming call, ensuring that it can automatically start and continue monitoring when power is restored after a power outage.
3. Breakpoint resume: During data transmission, if an interruption occurs, the system can automatically recover and continue to transmit data to ensure the integrity and accuracy of the data.
4. Permission management: The system has the permission group management function, which can grant different permissions to different users to ensure the security and controllability of the system.
5. Data management: The system can store and manage a large amount of historical data and alarm information, making it convenient for users to query and analyze.
6. Alarm management: The system has multiple alarm notification methods, such as on-site voice alarm, SMS alarm, telephone language alarm, sound and light alarm and E-Mail alarm, etc., to ensure that relevant personnel can be notified in time for processing when an abnormality occurs.
7. Remote management: Users can remotely access and manage the system through the network to achieve unified management and monitoring across regions.
8. Systematic linkage: The system can realize linkage and coordination among various subsystems to improve overall monitoring efficiency and management level.
9. Online maintenance: The system supports online maintenance and upgrades, making it convenient for users to maintain and update the system.
10. Expandable functions: The system is expandable and can add new monitoring equipment and functions according to user needs.
04. Technical features
1. Embedded monitoring system: adopts the industry’s advanced embedded integrated monitoring host, hard disk-free design, low power consumption, high stability and long service life.
2. Centralized monitoring system: adopts B/S architecture, supports monitoring and management of multiple acquisition devices, with user-friendly interface and easy operation.
3. Cloud deployment: The system supports cloud deployment, such as Alibaba Cloud, Tencent Cloud, etc., to achieve unified management across regions.
4. Easy installation and maintenance: The monitoring host has an integrated hardware and software design, which is highly integrated, easy to construct, and has simple wiring, minimizing the impact on existing equipment in the computer room.
5. Complete alarm functions: The platform has various alarm notification methods and flexible management, ensuring that relevant personnel can be notified in time for processing when an abnormality occurs.
6. Large system capacity: The system’s total data processing capacity is no less than 500,000 measurement points, supporting more than 100 browser clients to access simultaneously, meeting large-scale monitoring needs.
The centralized monitoring system for power environment in smart power distribution rooms has been applied in many fields, such as rail transit, industry, and construction. Through this system, the power distribution room can be unmanned or less manned, significantly improving the operation efficiency and management level. For example, in the power distribution room of a coal washing plant, the system effectively reduces the number of manual inspections through automatic inspection and early warning functions, detects potential risks of equipment in advance, and saves maintenance time.
The centralized monitoring system of power environment in smart distribution rooms conforms to the development direction of intelligence and provides impetus for the development of new quality productivity. It not only ensures the safe and efficient operation of the environment and equipment in the customer’s distribution room, but also improves the utilization rate and operation management level of the distribution room. It has broad application prospects and practical benefits.
